Description
Key Technical Specifications
- Model Number: CC-TAID01 / 51306733-175
- Manufacturer: Honeywell
- System Series: Experion PKS / C300 DCS
- Board Type: Analog Input (AI) I/O Terminal Board
- Primary Function: Field wiring interface for analog signals
- Signal Type: Supports 4-20mA and HART protocols
- System Role: Connects field devices to C300 I/O modules
- Mounting Style: DIN rail / Cabinet backplane
- Application: Process variable acquisition
- Industry: Petrochemical, Power Generation, Oil & Gas
Functional Role & Application Analysis
The Honeywell CC-TAID01 (51306733-175) is a dedicated Analog Input I/O terminal board designed specifically for the C300 Distributed Control System. It serves as the critical physical interface between field instruments and the active AI processing modules. Engineers rely on this terminal base to solve complex field wiring challenges, providing a secure, organized, and reliable connection point for 4-20mA and HART signals. By separating the field wiring from the active electronics, it simplifies maintenance and reduces the risk of damaging sensitive controller components during troubleshooting.
Typical use cases for this module include:
- Process Variable Acquisition: Terminating 4-20mA signals from temperature, pressure, and flow transmitters in refining and chemical plants.
- HART Instrumentation: Providing the necessary wiring infrastructure for smart HART-enabled field devices to communicate with the C300 controller.
- System Maintenance & Upgrades: Replacing degraded or damaged terminal bases during plant turnarounds without replacing the active I/O modules.
- Control Panel Construction: Serving as the standard field interface in OEM-built Experion control cabinets.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. We have established a rigorous, multi-stage testing process to ensure every CC-TAID01 we ship is 100% functional and ready for immediate installation.
- Visual & Component Inspection: All terminal boards undergo professional cleaning and microscopic inspection to ensure no physical damage, corrosion, or compromised solder joints.
- Live System Test: The terminal base is installed in a live Honeywell C300 test rack and run continuously to verify stable mechanical and electrical connections.
- Full-Function Diagnostics: We simulate 4-20mA signals across all channels to test the integrity of the signal paths and verify zero voltage drop or signal degradation.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
Honeywell CC-TAID01 51306733-175
Compatibility & Migration Paths
To ensure this CC-TAID01 (51306733-175) is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk that leads to costly installation delays.
- System Architecture: Confirm your system is a Honeywell C300 controller platform. This terminal board is designed specifically for AI modules and is not interchangeable with other Honeywell platforms.
- Module Pairing: Verify that you are using compatible AI modules (e.g., CC-PAIH01 or CC-PAIX01). The terminal board must match the specific I/O module’s pinout requirements.
- Redundancy Requirements: If your application requires redundant AI wiring, ensure you are ordering the correct redundant variant (e.g., CC-TAIX11) rather than the standard non-redundant CC-TAID01.
- Get Expert Help: Unsure about your system’s exact wiring configuration or module compatibility? Contact our technical team today for a free compatibility check before ordering.
