Description
Key Technical Specifications
- Model Number: GPD506V-B004
- Manufacturer: MAGNETEK / Yaskawa
- Series: GPD506 / CIMR-P5 Series
- Rated Power: 3 HP
- Input Voltage: 3-Phase 380-460 VAC
- Output Current: 4.8 Amps (5.1A Max)
- Output Frequency: 0-400 Hz
- Input Frequency: 50/60 Hz
- Control Type: AC VS Drive (V/Hz)
- Enclosure: Open Chassis / Panel Mount
Functional Role & Application Analysis
The MAGNETEK GPD506V-B004 is a general-purpose AC drive designed for standard variable torque and constant torque motor control applications. It solves the problem of providing reliable speed control for 3HP motors in legacy manufacturing equipment where modern drives may not fit existing panel cutouts or require extensive reprogramming. This drive accepts 380-460VAC 3-phase input and delivers a 0-460VAC output, making it a direct drop-in replacement for failed units in older machinery. The GPD506 architecture is known for its simple keypad interface and robust I/O for basic start/stop, speed reference, and fault signaling.
Typical use cases include:
- Conveyor & Fan Control: Driving 3HP fans, blowers, and conveyor belts in packaging or material handling lines.
- Pump Applications: Providing variable speed control for coolant pumps or transfer pumps in legacy process equipment.
- Legacy Machine Maintenance: Replacing failed GPD506V-B004 units in aging CNC machines, mixers, or presses without modifying the control panel.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable drive is far greater than its purchase price. We have established a rigorous, multi-stage testing process to ensure every GPD506V-B004 we ship is 100% functional.
- Visual & Component Inspection: All drives undergo professional cleaning and visual inspection to ensure no physical damage, capacitor bulging, or IGBT degradation.
- Live System Test: The drive is installed on a test bench with a 3HP motor and run for 24 hours to verify continuous operation, thermal stability, and cooling fan function.
- Full-Function Diagnostics: We simulate 0-10V speed references, test digital I/O, verify fault detection (overcurrent, overvoltage), and confirm parameter storage.
- Warranty Backing: Only drives that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
MAGNETEK-GPD506V-B004
Compatibility & Migration Paths
To ensure this GPD506V-B004 is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk.
- Voltage & Phase Confirmation: Verify your power supply is 3-Phase 380-460VAC. This drive will NOT work on single-phase 230V or 575V systems.
- Motor Nameplate Match: Confirm your motor is rated for 3HP at 460V with a full load current ≤ 4.8A. Oversized motors will cause immediate overcurrent faults.
- Wiring & Terminal Layout: The GPD506V-B004 uses a specific terminal block layout. Verify your existing wiring matches the R/S/T input and U/V/W output terminals before installation.
- Parameter Transfer: If replacing a failed unit, you must manually re-enter motor nameplate data, acceleration/deceleration times, and I/O configuration. The drive does not auto-transfer parameters.
- Get Expert Help: Unsure about your system? Contact our technical team today for a free compatibility check.
