Description
Key Technical Specifications
- Model Number: CC-TAIX11
- Part Number: 51308365-175
- Manufacturer: Honeywell
- Series: Experion PKS / C300 Controller
- Module Type: Redundant Analog Input Module (RAIM) Baseboard
- Channels: 16 Analog Input Channels
- Input Range: 0-20V, 4-20mA
- Resolution: 16-bit
- Accuracy: ±0.1%
- Isolation: 500V
- System Compatibility: C300 Controller, IOTA Baseboard Architecture
- Application Support: Safety Instrumented Systems (SIS)
Functional Role & Application Analysis
The Honeywell CC-TAIX11 is a critical redundant analog input baseboard designed for the C300 controller platform. It serves as the physical and electrical foundation for high-availability analog signal acquisition in industrial process control. By supporting redundant configurations, this baseboard ensures that if one processing path fails, the system seamlessly continues to capture critical field data without interrupting operations. It is specifically engineered to support Safety Instrumented System (SIS) applications where reliability is non-negotiable.
Typical use cases include:
- High-availability process control environments requiring redundant analog signal acquisition.
- Safety Instrumented Systems (SIS) where ±0.1% accuracy and 500V isolation are mandatory.
- Continuous monitoring of critical process variables like pressure, temperature, and flow.
- Integration with the Experion PKS Control Builder environment for modular batch automation.
- Replacing failed or obsolete analog input baseboards in legacy C300 DCS architectures.
Our Quality Standard & Testing Process
We understand that a failed redundant baseboard compromises the entire fault-tolerant architecture of a C300 system. Every CC-TAIX11 we ship goes through a strict validation process to ensure it performs exactly as specified. We do not rely on factory seals alone. Our technicians verify electrical integrity and redundancy readiness before the part leaves our facility.
- Visual & Component Inspection: Boards are cleaned and inspected under magnification. We check for cold solder joints, connector pin damage, and component discoloration.
- Live System Test: Each baseboard is installed in a live C300 test rack and run for a minimum of 4 hours to verify continuous operation and redundant communication handshake.
- Full-Function Diagnostics: We inject test signals across all 16 channels to validate 16-bit resolution, ±0.1% accuracy, and 500V isolation integrity.
- Warranty Backing: Only units passing all tests receive our 12-month warranty. We stand behind the hardware we sell.
Honeywell CC-TAIX11 51308365-175
Compatibility & Migration Paths
Do not assume this baseboard is a universal drop-in replacement. The IOTA architecture has strict hardware dependencies. Installing an incompatible baseboard can prevent redundant modules from functioning or cause SIS application faults. Verify these points before ordering.
- Module Compatibility: This baseboard is designed for redundant analog input modules. Verify your existing I/O modules are compatible with the CC-TAIX11 RAIM architecture.
- Firmware/Hardware Revisions: Confirm your controller firmware supports the CC-TAIX11 revision you are ordering. Earlier firmware versions may not recognize newer hardware revisions.
- Replacement & Alternatives: Check the full part number on your existing baseboard’s label (51308365-175). If you do not require redundancy, the CC-TAIX01 (51308363-175) may be a cost-effective alternative. For HART protocol support, verify if the CC-PAIH01 module is required instead.
- Get Expert Help: Send us a photo of your current baseboard’s nameplate and your controller’s software version. Our team will confirm compatibility before you commit to a purchase.
