Description
Key Technical Specifications
- Model Number: V7768-322001
- Manufacturer: GE Fanuc Intelligent Platforms
- Product Type: VMEbus Single Board Computer
- Processor: Intel Core 2 Duo (up to 2.16 GHz)
- Memory: Up to 2 GB DDR2 SDRAM (Single SODIMM)
- Network Interfaces: Dual Gigabit Ethernet (Front Panel RJ45)
- Storage Interfaces: Up to 8 GB Bootable CompactFlash, 2x SATA
- Expansion: 1x PCI-X PMC Expansion Site
- Front Panel I/O: 2x Serial, 4x USB 2.0, PS/2 Keyboard/Mouse
- OS Support: Windows XP, VxWorks, Linux
Functional Role & Application Analysis
The GE V7768-322001 is a high-performance VMEbus single board computer designed for demanding embedded and industrial applications. It is primarily used to solve the need for high-speed data processing and complex control algorithms within legacy VME architectures. By integrating an Intel Core 2 Duo processor and rich I/O options onto a standard Eurocard form factor, this module bridges the gap between traditional industrial backplanes and modern computing requirements.
Typical use cases for this module include:
- Defense & Aerospace Systems: Serving as the central processing unit in radar, avionics, and secure communications equipment requiring VME64 compatibility.
- Industrial Automation: Acting as a high-speed system controller or peripheral CPU in manufacturing execution systems and complex machinery control.
- Telecommunications Infrastructure: Managing high-bandwidth data routing and signal processing in legacy telecom switching and network equipment.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. A failed system controller in a critical infrastructure application can lead to severe operational disruptions. We have established a rigorous, multi-stage testing process to ensure every V7768-322001 we ship is 100% functional and ready for critical duty.
- Visual & Component Inspection: All parts undergo professional cleaning and detailed visual inspection under magnification to ensure no physical damage, corrosion, or compromised components exist on the board.
- Live System Test: The module is installed in a live VME test rack and run for a minimum of 24 hours to verify continuous operation, thermal stability, and backplane communication.
- Full-Function Diagnostics: We simulate real-world I/O signals, network traffic, and storage operations to test the full range of processing capabilities, ensuring accurate data handling and zero latency.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty, giving you complete confidence in your spare parts strategy.
GE-V7768-322001
Compatibility & Migration Paths
To ensure this V7768-322001 is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk that can lead to installation failures or unexpected system faults.
- VME Backplane Compatibility: You must confirm your existing VME backplane supports VME64 mode and provides the necessary P2 connector for the rear I/O. Older VME32 backplanes may limit functionality.
- Operating System & Drivers: Verify your application software and OS (Windows XP, VxWorks, or Linux) are compatible with the Intel Core 2 Duo architecture and the 945GME chipset. Legacy OS versions may require specific driver packages.
- Expansion Modules: If utilizing the PMC expansion site, ensure your daughter cards are PCI-X compatible and that the mechanical clearance in your chassis accommodates the module’s height.
- Get Expert Help: Unsure about your backplane compatibility or OS requirements? Contact our technical team today for a free compatibility check and engineering support.
