Description
Key Technical Specifications
- Model Number: ADEPT 320-1026C
- Manufacturer: ADEPT
- Series: ADEPT 320 Series
- Product Type: Analog Signal Acquisition Module
- Channel Count: 16 Independent Channels
- Resolution: 16-bit
- Sampling Rate: Up to 100 kHz
- Input Range: -10 V to +10 V
- Input Impedance: 10 MΩ
- Protection Rating: IP65
Functional Role & Application Analysis
The ADEPT 320-1026C is a high-precision data acquisition module built for demanding industrial and test environments. It solves the challenge of capturing fast, dynamic analog signals with high fidelity. By converting multi-channel analog inputs into accurate digital data, this module ensures control systems and analysis software receive reliable, real-time information. Its 16-bit resolution and 100 kHz sampling rate make it suitable for high-speed monitoring tasks where precision matters.
Typical use cases include:
- Use Case 1: Industrial process control systems requiring simultaneous, high-speed data collection from multiple sensors and transmitters.
- Use Case 2: Test and measurement applications for validating electronic equipment parameters like voltage, current, and power.
- Use Case 3: Scientific research setups that demand accurate, high-resolution data logging for dynamic physical phenomena.
- Use Case 4: Machine simulation and hardware-in-the-loop (HIL) testing requiring precise analog feedback.
- Use Case 5: Critical maintenance and replacement in legacy ADEPT 320 series installations.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable data acquisition module is far greater than its purchase price. Inaccurate readings can lead to faulty control decisions and compromised test results. We have established a rigorous, multi-stage testing process to ensure every 320-1026C we ship is 100% functional and meets its specified performance standards.
- Visual & Component Inspection: All parts undergo professional cleaning and visual inspection to ensure no physical damage, corrosion, or compromised components on the PCB.
- Live System Test: The module is installed in a live ADEPT test rack and run for 24 hours to verify continuous operation, thermal stability, and communication integrity.
- Full-Function Diagnostics: We simulate -10V to +10V signals across all 16 channels to test the full range, verify 16-bit accuracy, and confirm the 100 kHz sampling rate.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
ADEPT-320-1026C
Compatibility & Migration Paths
To ensure this 320-1026C is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk that can delay commissioning.
- Firmware/Hardware Revisions: You must confirm your host system or data acquisition software supports the 320 series modules and can handle 100 kHz sampling rates. Older software may not recognize the full capabilities of this card.
- Required Components: This module requires a compatible DIN rail mounting setup and proper shielding for analog input cables to maintain signal integrity in electrically noisy environments.
- Replacement & Alternatives: This model provides 16 channels. If your application requires fewer channels, you may consider the 320-1004C or 320-1008C as cost-effective alternatives. For higher channel density, the 320-1032C or 320-1064C are available.
- Get Expert Help: Unsure about your system? Contact our technical team today for a free compatibility check.
