Description
Key Technical Specifications
- Model Number: ETT-VGA-0045
- Manufacturer: UNIOP (EXOR)
- Series: ETT-VGA Touch Screen Series
- Product Type: Graphical Touch Screen HMI
- Display Type: VGA Color Graphics
- User Interface: Analog Touch Screen with Configurable Function Keys
- Data Logging: Built-in Battery-Backed Real-Time Clock
- Alarm Capacity: Monitors up to 1024 Alarms
- Security: 8-Level Password Protection Scheme
- Application: Industrial automation, machine control, and process monitoring
Functional Role & Application Analysis
The UNIOP ETT-VGA-0045 is a dedicated graphical touch screen designed to serve as the primary operator interface for industrial machinery. Its primary role is to provide real-time visualization of process data, alarm management, and direct control inputs. In older manufacturing environments, replacing proprietary pushbuttons and analog gauges with a single HMI drastically reduces panel wiring and speeds up troubleshooting. This module solves that exact problem by consolidating machine status and control into one interactive VGA display. It features eight configurable function keys and user-defined LEDs, allowing operators to interact with the system intuitively. The unit also supports data scaling and formats readings as bar graphs, decimals, or strings.
Typical use cases include:
- Machine Control Panels: Serving as the primary operator interface for packaging machines, CNC equipment, and assembly lines.
- Alarm & Event Logging: Tracking up to 1024 alarms and storing the last 256 events for maintenance diagnostics and historical analysis.
- Legacy System Maintenance: Replacing failed or obsolete touch screens in existing EXOR/UNIOP installations to restore production visibility.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. A dead HMI means operators are flying blind, leading to extended downtime. We have established a rigorous, multi-stage testing process to ensure every ETT-VGA-0045 we ship is 100% functional and ready for immediate deployment.
- Visual & Component Inspection: All modules undergo professional cleaning and high-magnification visual inspection. We check the touch screen membrane for dead zones, physical damage, and compromised solder joints.
- Live System Test: The HMI is installed in a live UNIOP test environment and run continuously to verify stable operation, backlight integrity, and touch responsiveness.
- Full-Function Diagnostics: We test the communication ports, verify the real-time clock battery, and simulate alarm conditions to ensure the 1024-alarm capacity and password protection functions operate correctly.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
UNIOP ETT-VGA-0045
Compatibility & Migration Paths
To ensure this ETT-VGA-0045 is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk that leads to costly installation delays.
- Exact Part Number Match: You must confirm your existing screen matches both the model (ETT-VGA-0045) and the specific hardware revision. UNIOP has released multiple variants over the years.
- Software & Memory: Verify that your existing application program is compatible with this screen’s memory configuration. Some older programs may require memory expansion modules (like the MEM10 B 32MB) to run properly.
- Communication Port: Confirm the physical communication port type (e.g., RS-232, RS-485) and protocol matches your existing PLC or controller.
- Get Expert Help: Unsure about your system’s compatibility? Send us a photo of your current HMI’s nameplate and your PLC model. Our technical team will verify the exact match before you order.
