Description
Key Technical Specifications
- Model Number: UTLH21
- Manufacturer: Toshiba
- Product Type: Industrial PLC / IO Controller Module
- Processor: 32-bit RISC Processor
- Memory: 512 KB RAM / 2 MB Storage
- Power Supply: 24 VDC
- Power Consumption: 50 W
- I/O Interfaces: Digital, Analog, and Pulse I/O
- Supported Protocols: T-Cnet IO, NV System
- Communication Speed: 10/100 Mbit/s
- Operating Temperature: -40°C to 125°C
- Environmental Humidity: 5% to 95% (Non-condensing)
- Dimensions: 220 mm x 160 mm x 41 mm
- Weight: 1.3 kg
Functional Role & Application Analysis
The Toshiba UTLH21 is a high-performance industrial controller designed to manage complex automation tasks and serve as the communication bridge between a central PLC and peripheral field devices. It solves critical integration challenges by converting weak processor signals into strong field signals to drive actuators, while simultaneously reading limit switches and sensors. Built on a 32-bit RISC architecture, this module delivers high-speed logic processing and rapid response times required for demanding industrial environments.
- Peripheral Signal Bridging: Routes various control signals (switching values and analog values) between the PLC and field equipment, ensuring accurate data transmission.
- Heavy Industry Process Control: Manages high-speed logic and I/O processing in manufacturing, energy, and transportation sectors.
- High-Power Load Management: Utilizes optically isolated relay, transistor, or thyristor outputs to safely drive high-power and high-speed field loads.
- Legacy System Maintenance: Replaces obsolete controller boards in aging Toshiba T-Cnet or NV System infrastructure, preventing costly system-wide retrofits.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. A failed controller module can halt an entire production line. We have established a rigorous, multi-stage testing process to ensure every UTLH21 we ship is 100% functional.
- Visual & Component Inspection: All parts undergo professional cleaning and high-magnification visual inspection to ensure no physical damage, corrosion, or compromised solder joints.
- Live System Test: The module is installed in a live Toshiba test rack and run for 24 hours to verify continuous operation, 24 VDC power stability, and thermal performance.
- Full-Function Diagnostics: We simulate digital, analog, and pulse signals to test the full range and accuracy of every channel, verifying T-Cnet communication and logic execution.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
TOSHIBA UTLH21
Compatibility & Migration Paths
To ensure this UTLH21 is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk.
- System Platform Verification: Confirm your system is running the Toshiba T-Cnet IO or Unifi NV platform, as this module is specifically designed for these architectures.
- Power Supply Verification: Verify your control panel provides a stable 24 VDC power supply capable of supporting the 50 W power consumption of this controller.
- I/O Module Matching: Ensure your existing peripheral I/O modules and wiring match the digital, analog, and pulse configurations expected by this UTLH21 unit.
- Get Expert Help: Unsure about your system? Contact our technical team today for a free compatibility check.
