Description
Key Technical Specifications
- Model Number: DS200SDCCG1AGD / DS215SDCCG1AZZ01B
- Manufacturer: GE. Series: Mark V / DS200 Drive Control
- Module Type: Drive Control Board / LAN Communications Card
- Processor: Triple microprocessor architecture with shared RAM
- Operating Voltage: 18.5 to 36 VDC
- Operating Temperature: -5°C to +55°C
- Communication: LAN communication interface for Mark V network
- Diagnostics: 10 LED fault code indicator array
- Mounting: Backplane plug-in within DS200 drive/excitation racks
- Weight: Approximately 1.29 kg
GE-DS200SDCCG1AGD-DS215SDCCG1AZZ01B
Functional Role & Application Analysis
The GE DS200SDCCG1AGD is the primary drive controller for GE’s Mark V series, serving as the central processing unit for industrial drives and excitation systems. It solves the critical need for deterministic, high-speed loop control in mission-critical power generation and heavy industrial applications. Equipped with three microprocessors and shared RAM, this board executes core current/voltage loop algorithms and firing logic. The DS215SDCCG1AZZ01B variant serves as the LAN communications card, enabling seamless data exchange across the Mark V control network.
- EX2000 Excitation Systems: Providing precise voltage regulation and reactive power control for synchronous generators.
- DC2000 & AC2000 Drives: Managing variable speed drive operations in metals, paper, and mining applications.
- Speedtronic Mark V Panels: Serving as the core DSPC (Digital Signal Processor Control) board in gas and steam turbine control cabinets.
- Legacy System Maintenance: Replacing failed drive control boards in aging GE infrastructure to prevent catastrophic turbine trips.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. A failed drive controller can result in an unplanned turbine trip costing hundreds of thousands of dollars per hour. We have established a rigorous, multi-stage testing process to ensure every DS200SDCCG1AGD we ship is 100% functional.
- Visual & Component Inspection: All units undergo professional cleaning and microscopic inspection to verify no physical damage, corrosion, or compromised solder joints.
- Live System Test: The module is installed in a live Mark V test rack and run for 24 hours to verify continuous operation, processor synchronization, and thermal stability.
- Full-Function Diagnostics: We simulate drive feedback signals and LAN traffic to test the full range of I/O processing, DSP loop execution, and LED diagnostic reporting.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
GE-DS200SDCCG1AGD-DS215SDCCG1AZZ01B
Compatibility & Migration Paths
To ensure this DS200SDCCG1AGD is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk that leads to costly commissioning delays.
- Firmware/EPROM Revisions: You must confirm your existing firmware version matches. The AGD revision must be compatible with your current Mark V software release; mismatched EPROMs will prevent the board from booting.
- Board Family Compatibility: Verify your backplane supports the H1 family DS200 boards. The DS215SDCCG1AZZ01B LAN card must match the SDCC board’s communication protocol version.
- Replacement & Alternatives: DS200SDCCG1AGD is a specific revision. If replacing an older revision (e.g., AFD), confirm form/fit/function compatibility. The ADA revision is typically a drop-in replacement for H1 series builds.
- Get Expert Help: Unsure about your Mark V configuration or firmware requirements? Contact our technical team today for a free compatibility check.
