Description
Key Technical Specifications
- Model Number: P0916PWOC
- Manufacturer: Foxboro (Invensys / Schneider Electric)
- Product Type: Fieldbus Communication Module
- Supported System: I/A Series DCS
- Communication Speed: 2 Mbps Fieldbus
- Module Function: MODULE COMMUNICATION
- Operating Voltage: 12.5-42 VDC
- Operating Temperature: 0°C to 60°C
- Environmental Humidity: 5% to 95% (Non-condensing)
- Installation: Control Room Rack Mount
- Certifications: CE
- Origin: United States
Functional Role & Application Analysis
The Foxboro P0916PWOC is a dedicated communication module designed to serve as a high-speed data bridge within the I/A Series distributed control system. It solves the critical need for reliable, deterministic fieldbus communication between the central controller and remote I/O subsystems or intelligent field devices. This module ensures that process data and control commands are transmitted with integrity across the plant’s communication backbone.
- Fieldbus Network Backbone: Provides the 2 Mbps communication link essential for connecting distributed I/O racks to the main control processor.
- System Expansion: Enables the addition of new process units or remote panels to an existing I/A Series network without disrupting current operations.
- Legacy System Maintenance: Replaces failed communication cards in aging I/A Series installations to restore critical network links and prevent data loss.
- High-Integrity Data Transfer: Ensures robust communication in electrically noisy industrial environments, maintaining system stability and control.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. A failed communication module can isolate entire sections of your control network. We have established a rigorous, multi-stage testing process to ensure every P0916PWOC we ship is 100% functional.
- Visual & Component Inspection: All parts undergo professional cleaning and high-magnification visual inspection to ensure no physical damage, corrosion, or compromised solder joints.
- Live System Test: The module is installed in a live Foxboro test rack and run for 24 hours to verify continuous operation, power draw, and thermal stability.
- Full-Function Diagnostics: We simulate fieldbus traffic to test communication integrity, verifying data throughput, error handling, and seamless integration with the I/A Series backplane.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
FOXBORO P0916PWOC
Compatibility & Migration Paths
To ensure this P0916PWOC is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk.
- Exact Part Number Match: Confirm your system requires the P0916PWOC specifically. Suffix variations (e.g., P0916PW) may indicate different hardware revisions or firmware.
- Backplane Compatibility: Verify that your I/A Series rack and backplane support this specific communication module type and its power requirements.
- Network Configuration: Ensure your system’s fieldbus configuration matches the 2 Mbps speed and addressing scheme expected by this module.
- Get Expert Help: Unsure about your system’s communication requirements? Contact our technical team today for a free compatibility check.
