Description
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Family | DeltaV S-Series (S800) |
| Model Number | SE3008 |
| Hardware P/N | KJ2005X1-SQ1 |
| Spare Part P/N | 12P6383X032 |
| Controller Type | DeltaV SQ Controller |
| I/O Architecture | CHARM-based Electronic Marshalling |
| Application Scope | Small to moderate process applications |
| Network | DeltaV Control Network |
| Field Device Support | Integrated field device communication |
| Origin | United States |
Product Introduction
You’ve got a skid-mounted package — maybe a chemical injection skid or a small utility unit — and running a full DeltaV AC800 controller is overkill. The SE3008 fills that gap. It sits in the DeltaV ecosystem as a compact S-Series controller, handling process logic and field device integration without the footprint or cost of a larger controller chassis.
The CHARM-based electronic marshalling is the key differentiator here. Instead of hardwiring each field device to a specific I/O card slot, CHARMs let you assign I/O type at configuration time rather than at hardware install time. That means your panel shop doesn’t need to know whether a terminal gets a 4-20 mA input or a discrete output until the project engineer locks down the I/O list. For small-to-moderate applications, the SE3008 keeps the hardware bill of materials lean while staying fully native to the DeltaV control network.
QA/QC Transparency SOP
- Intake & Origin Verification — Confirm the label reads “SE3008” with Emerson/DeltaV branding. Cross-check KJ2005X1-SQ1 and 12P6383X032 against the purchase order. Inspect the backplane connector pins for bending, corrosion, or carbon tracking. Verify the hardware revision suffix matches your DeltaV project’s compatibility matrix.
- Live Functional Testing — Mount in a powered DeltaV test rack or S-Series carrier. Confirm the controller powers up and the status LED indicates normal operation. Connect to the DeltaV network and verify the controller appears in Explorer without communication faults.
- Electrical Parameter Tests — Measure supply voltage at the input terminals against the rated specification. Check continuity on all backplane interface pins. Megger isolation between field-side terminals and logic ground if applicable to your installation environment.
- Firmware/Config Verification — Read the firmware revision via DeltaV Explorer. Compare against the project’s configuration database to confirm compatibility. Back up any existing configuration from the unit’s non-volatile memory before shipping.
- Final QC & Anti-Static Packaging — Log the hardware revision, firmware version, LED status, and network communication test result. Package in an ESD-safe bag with connector pins capped. Include a printed test certificate with the shipment.
Field Engineer Gotchas
- Part Number Confusion Across Suffixes: The SE3008 ships under multiple hardware suffixes — KJ2005X1-SQ1, KJ2005X1-MQ2, KJ2005X1-BK1, etc. These are not always interchangeable. A unit configured for one DeltaV firmware generation may not accept a project built for another. Solution: Always match the full KJ2005X1-xxx suffix to your existing installation, or confirm firmware compatibility with Emerson before ordering a different suffix.
- CHARM Carrier Compatibility: The SE3008 uses CHARMs for I/O, but the CHARM carriers must match the controller’s hardware revision. Mixing CHARM carrier revisions from a VE3008 or SE3007 into an slot can cause marshalling failures that show up as phantom I/O faults. Solution: Verify the CHARM carrier part number against the hardware manual before populating I/O slots.
- DeltaV Explorer Version Lock: The controller firmware must be compatible with the DeltaV Explorer version on your engineering workstation. A newer Explorer may refuse to download to an older controller firmware, or vice versa. Bottom line — check the Emerson compatibility matrix before you show up on-site with a laptop full of the wrong software version.
- Spare Part Number vs. Hardware Part Number: The 12P6383X032 is a spare/replacement part number, not the hardware model number. Procurement teams sometimes order by one number and receive a unit labeled with the other. They refer to the same product, but the label on the physical unit will read KJ2005X1-SQ1, not 12P6383X032. Don’t reject a shipment thinking you got the wrong part.
EMERSON SE3008 KJ2005X1-SQ1 12P6383X032
Application Scenarios
- Chemical Injection Skids: Compact dosing packages on offshore platforms where a full DeltaV controller is excessive but native DeltaV network integration is required for alarm and historian reporting.
- Small Utility Boilers: Package boilers in manufacturing plants that need local combustion control with DeltaV supervisory oversight, where the handles the burner management logic and feeds data back to the host DCS.
- Water Treatment Dosing Stations: Municipal or industrial water treatment facilities where chemical feed pumps, flow meters, and analyzers are controlled locally via CHARMs, with the acting as the local controller node on the plant’s DeltaV network.
- Pharmaceutical Batch Process Units: Small-scale reactor or blending skids in pharma facilities where the CHARM-based marshalling allows I/O reassignment between product campaigns without rewiring the panel.
Field Note: A mid-size chemical plant added a new solvent recovery skid to an existing DeltaV system. The project spec called for an with CHARM-based I/O. The procurement team sourced a surplus unit with the correct KJ2005X1-SQ1 part number, but the firmware revision was two generations behind the plant’s DeltaV Explorer version. The controller powered up fine and showed healthy on the network, but Explorer refused to download the project — it threw a firmware mismatch error. The fix was a field firmware upgrade using Emerson’s recovery tools before the project download would proceed. Always verify firmware revision against your engineering station version before commissioning a surplus controller.
FAQ
No. They are related S-Series controllers but carry different model designations (SE vs. VE) and may have different hardware capabilities or firmware support. Do not assume drop-in interchangeability without checking the DeltaV hardware compatibility documentation.
What does the 12P6383X032 number mean?
That is the Emerson spare part number for the KJ2005X1-SQ1. The is the hardware model number printed on the unit. Both refer to the same product — one is for ordering, the other is for identification.
Does this controller support CHARMs natively?
Yes. The is designed around CHARM-based electronic marshalling. You assign I/O function (analog input, analog output, discrete, etc.) through CHARM modules rather than fixed-function I/O cards.
Can I use this controller standalone without a DeltaV host system?
The is a DeltaV controller — it executes control logic and communicates over the DeltaV network. It can operate as a local controller on a skid, but configuration, monitoring, and project management are done through DeltaV Explorer on an engineering workstation.
Is this unit still supported by Emerson?
The S-Series platform is a legacy DeltaV product line. Support status, firmware updates, and spare parts availability should be confirmed directly with Emerson or an authorized DeltaV service provider before committing to a procurement decision.
What firmware version do I need?
That depends entirely on your DeltaV system version and the DeltaV Explorer release on your engineering station. There is no single “correct” firmware — it must match your project environment. Check the Emerson DeltaV release compatibility documentation.
They can coexist on the same DeltaV control network, but they are different controller models with potentially different I/O capacities and feature sets. Each must be configured independently in DeltaV Explorer. Verify that your project architecture supports mixed controller types in the same area.
