Description
Key Technical Specifications
- Model Number: SE3007 (KJ2005X1-BK1)
- Manufacturer: Emerson
- Series: DeltaV SX / SQ Controller Family
- Type: Process Automation Controller
- User Memory: 96 MB
- Module Execution Rates: 100ms, 200ms, 500ms, 1s, 2s, 5s, 10s, 30s, 60s
- Data Throughput: 4000 values/sec (Transmit), 500 values/sec (Receive)
- SCADA Tags: 3200 Tags
- Redundancy: 1:1 Hot Standby Supported
- Operating Temperature: -40°C to +60°C
- Power Consumption: 5.0 W Typical (7.0 W Max)
- Internal Protection: 3.0 A Non-replaceable Fuse
Functional Role & Application Analysis
The Emerson SE3007 is the workhorse processing engine for the DeltaV SX controller family. It handles the heavy lifting of executing control logic, managing I/O data, and maintaining network communications. Designed with electronic marshalling based on CHARMs, this controller eliminates the traditional wiring headaches of fixed I/O mapping. It gives engineers the flexibility to assign I/O functions dynamically, drastically speeding up project execution and cabinet assembly.
Typical use cases include:
- Power Generation DCS: Managing boiler and turbine control loops where 1:1 redundancy is mandatory for continuous uptime.
- Petrochemical Processing: Executing complex regulatory and batch control strategies across thousands of SCADA tags.
- Legacy System Maintenance: Replacing failed SX controllers in aging DeltaV plants where keeping the exact hardware revision is critical for system stability.
Our Quality Standard & Testing Process
A controller failure means a loss of plant visibility and control. We don’t ship untested CPUs. Every SE3007 undergoes a rigorous validation process to ensure it boots, communicates, and executes logic flawlessly before it reaches your facility.
- Visual & Component Inspection: We inspect the PCB for thermal damage, capacitor degradation, and backplane connector integrity. The non-replaceable 3.0A internal fuse is verified for continuity.
- Live System Test: The module is installed in a DeltaV test chassis and powered up. We verify the boot sequence, confirm it achieves 1:1 redundancy synchronization, and validate network communication.
- Full-Function Diagnostics: We execute test control strategies at various execution rates (from 100ms to 60s) to verify CPU timing and memory allocation. We confirm the 96MB user memory is fully accessible and error-free.
- Warranty Backing: Only controllers passing all functional and communication tests ship with our 12-month warranty. We provide test logs confirming operational integrity.
EMERSON SE3007-12P4688X032-0022E51FB6DA-KJ2005X1-BK1
Compatibility & Migration Paths
The SE3007 is a specific DeltaV SX controller. Mixing controller types or revisions in a redundant pair will cause synchronization failures. You must verify exact compatibility before ordering.
- Firmware/Hardware Revisions: Check the revision level on your existing SE3007. The full part number (12P4688X032-0022E51FB6DA-KJ2005X1-BK1) encodes specific hardware and firmware configurations. Redundant controllers must match exactly.
- Required Components: Verify your I/O chassis and CHARM configuration. The SE3007 requires compatible SX I/O modules and proper electronic marshalling setup.
- Replacement & Alternatives: The SE3006, SE3008, or VE3007 may be related models in the DeltaV family. For direct swaps, confirm the and KJ2005X1-BK1 suffixes match your existing unit precisely.
- Get Expert Help: Send us a photo of your current controller’s nameplate and your DeltaV system configuration. We will confirm the is compatible or identify the correct migration path before you commit.
