GE IS215UCVEM09A | Mark VI VME Controller, 300 MHz Celeron
GE IS215UCVEM09A | Mark VI VME Controller, 300 MHz Celeron - Image 2
GE IS215UCVEM09A | Mark VI VME Controller, 300 MHz Celeron - Image 3

GE IS215UCVEM09A | Mark VI VME Controller, 300 MHz Celeron

  • Model: IS215UCVEM09A
  • Brand: GE (General Electric)
  • Series: Speedtronic Mark VI
  • Core Function: Single-slot VME controller board for GE turbine and balance-of-plant control applications.
  • Type: CPU / Controller Board
  • Key Specs: 300 MHz Intel Celeron processor, 16 MB Flash + 32 MB DRAM, QNX real-time OS, 10BaseT/100BaseTX Ethernet, dual RS-232C serial ports.
Get a Quote
Category:
Phone: +86 15383419322
Email: [email protected]
WhatsApp: +86 15383419322
WhatsApp QR Code
Brand:

Description

Key Technical Specifications

Parameter Specification
Processor Intel Celeron 300 MHz
Flash Memory 16 MB
DRAM 32 MB
Operating System QNX Real-Time OS
Ethernet 1 × 10BaseT/100BaseTX (RJ-45)
Serial Ports 2 × RS-232C
Bus Interface VME
Form Factor Single-slot VME board
Execution Rate Up to 100,000 rungs/blocks per second (typical)
Clock Sync 100 μs via VCMI communication board
Display/Peripheral Keyboard, mouse, and display connectors (board-dependent)
Compatible Series GE Speedtronic Mark VI



Product Introduction

Finding a replacement controller for a legacy Mark VI turbine system is rarely a simple “order and swap” job. The IS215UCVEM09A is the single-slot VME processor board that sits at the heart of GE’s Speedtronic Mark VI architecture — handling control execution, VME bus communication with I/O boards via the VCMI interface, and network connectivity to the Toolbox engineering workstation.

What makes this board worth keeping in the spare-parts cabinet is its deterministic QNX runtime paired with a 300 MHz Celeron capable of executing up to 100,000 control blocks per second. The 100 μs clock synchronization through VCMI keeps singlex and TMR configurations locked tight. It’s not new hardware — but for plants running Mark VI, there’s no drop-in software substitute.

QA/QC Transparency SOP

  1. Intake & Origin Verification: Serial number, revision label, and physical condition logged. Source traceability documented to rule out pulls from flood-damaged or fire-affected racks.
  2. Live Functional Testing: Board seated in a verified VME test rack. Ethernet link-up confirmed, Toolbox communication established, and both RS-232 ports loopback-tested under load.
  3. Electrical Parameter Tests: Rail voltages checked with a calibrated Fluke multimeter. Continuity and insulation resistance verified across VME pins to rule out cold solder joints or bus shorts.
  4. Firmware/Config Verification: BIOS and QNX image read out. Firmware revision recorded and backed up. Any existing application data wiped unless specifically requested.
  5. Final QC & Anti-Static Packaging: Board cleaned, inspected under magnification, placed in an ESD-shielded bag with desiccant, and shipped in anti-static foam.



Field Engineer Gotchas

  • Firmware Revision Mismatch: A newer or older QNX image than the rest of your Mark VI rack will cause Toolbox connection timeouts or VCMI sync failures. Always dump the firmware revision before pulling the old board.
  • VME Slot Seating: These boards are heavy. A partially seated card will pass a bench test but fail intermittently in the rack. Reseat firmly and verify backplane pin alignment — I’ve seen a plant lose a day chasing a “bad board” that was just loose.
  • Battery-Backed Memory: If the board has an onboard RTC battery, a dead cell can corrupt configuration on power-down. Replace the battery proactively during overhaul outages.
  • ESD Handling: QNX flash is sensitive. Never handle the board outside an ESD strap and grounded mat. One static hit and you’ve got a paperweight.
GE IS215UCVEM09A

GE IS215UCVEM09A

Application Scenarios

  • Gas Turbine TMR Control Replacement: Swapping a failed controller in a redundant Mark VI turbine rack without rewriting the application logic.
  • Balance-of-Plant (BOP) Controller Upgrade: Replacing an aging CPU in a steam turbine or compressor control station where QNX determinism is still required.
  • Legacy Plant Spare Pool: Keeping a tested unit on the shelf for facilities that can’t justify a full Mark VIe migration yet.



FAQ

Is IS215UCVEM09A the same as IS215UCVEH2A?
No. They’re different revisions within the Mark VI controller family. Firmware and hardware differences may exist. Don’t mix them without validating with GE documentation.

Does this board support hot-swapping?
Mark VI controllers generally require a controlled shutdown for CPU replacement. Do not pull this board live unless your specific TMR configuration and procedures explicitly allow it.

Can I use this in a Mark VIe system?
No. Mark VIe uses a completely different hardware platform (UCVEx series). This board is for classic Mark VI only.

What’s the typical lead time for a tested unit?
Surplus stock varies. Reputable suppliers usually ship within 3–7 business days after QA. Avoid vendors who can’t provide a test report.

Does it come with the application loaded?
Typically no. Application software is site-specific and loaded via Toolbox. Expect a blank or generic QNX image unless otherwise stated.

Are there known counterfeit concerns?
Yes — GE turbine parts are frequently counterfeited in the surplus market. Always buy from a supplier that provides serial verification, test documentation, and a warranty.
