Description
Key Technical Specifications
- Model Number: IS200BPVCG1BR
- Manufacturer: GE (General Electric)
- System: Mark VI / Mark VIe Speedtronic
- Product Type: VME Backplane Board (BPVC)
- Form Factor: Standard GE IS200 Series
- Application: Gas/Steam Turbine Control & Protection
- Mounting: IS200 Rack Mount
- Revision: G1BR (Hardware/Firmware Revision Level)
- Origin: United States
Functional Role & Application Analysis
The GE IS200BPVCG1BR is a critical VME backplane board designed specifically for GE’s Mark VI and Mark VIe Speedtronic turbine control systems. It is primarily used to solve the complex routing and communication pain points within a turbine control rack. The BPVC board acts as the central nervous system of the rack, providing the physical backplane interconnects that allow the CPU, I/O modules, and communication cards to exchange high-speed data reliably.
Typical use cases include:
- Turbine Control Racks: Serving as the foundational backplane in Mark VI control cabinets for gas and steam turbines.
- System Upgrades: Supporting Mark VI to Mark VIe migration projects where legacy backplanes must be replaced or upgraded.
- Corrective Maintenance: Replacing failed backplane boards causing intermittent communication faults, VME bus errors, or module recognition failures.
- Legacy Plant Support: Providing critical spare inventory for aging power generation facilities to prevent extended forced outages.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable turbine control part is far greater than its purchase price. A backplane failure can strand an entire control rack, leading to catastrophic plant downtime. We have established a rigorous, multi-stage testing process to ensure every IS200BPVCG1BR we ship is 100% functional.
- Visual & Component Inspection: All boards undergo professional cleaning and visual inspection under magnification to ensure no physical damage, cracked solder joints, or compromised components exist.
- Live System Test: The board is installed in a live Mark VI test rack and run for 24 hours to verify continuous operation and backplane bus integrity.
- Full-Function Diagnostics: We simulate VME bus traffic and verify the board’s ability to route data accurately between CPU and I/O modules without data corruption or latency.
- Continuity & Impedance Testing: We test all backplane traces for proper continuity and impedance to ensure signal integrity meets GE specifications.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
GE IS200BPVCG1BR
Compatibility & Migration Paths
To ensure this GE IS200BPVCG1BR is 100% compatible with your Mark VI system, you must check these key compatibility points. Failure to verify this is a common project risk that leads to extended commissioning times and control rack failures.
- Hardware Revision Match: You must confirm your existing system’s hardware revision level. The “G1BR” suffix indicates a specific revision; mismatched revisions can cause VME bus timing issues.
- Rack Configuration: Verify that this backplane matches your specific rack size and slot configuration. BPVC boards are sized for specific rack depths and slot counts.
- Mark VI vs Mark VIe: Confirm whether your system is Mark VI or Mark VIe. While physically similar, the backplane architectures have critical differences that prevent cross-compatibility.
- Get Expert Help: Unsure about your Mark VI configuration or revision level? Contact our technical team today for a free compatibility check against your system documentation.
