Description
Key Technical Specifications
- Model Number: IC698CPE030
- Manufacturer: GE Fanuc / Emerson Automation
- Series: PACSystems RX7i
- Microprocessor: 600 MHz Pentium-M Processor
- User Memory: 64 MB RAM, 64 MB Flash Memory
- Boolean Execution Speed: 0.069 ms per 1000 instructions
- I/O Capacity: Up to 32K discrete I/O and 32K analog I/O words
- Communication Ports: Dual 10/100 Mbps Ethernet, 1x RS-232, 1x RS-485
- Supported Protocols: SRTP, Modbus TCP/RTU, EGD, SNP, Serial I/O
- Program Blocks: Up to 512 blocks (max 128 KB each)
GE-IC698CPE030
Functional Role & Application Analysis
The GE IC698CPE030 is a high-performance central processing unit designed for the PACSystems RX7i platform. It is primarily used to solve the challenge of managing complex, large-scale automation tasks that require computer-class processing power. By integrating a 600 MHz Pentium-M processor with dual Ethernet ports and built-in web server capabilities, this CPU enables real-time data processing, remote monitoring, and seamless integration across plant-wide networks. It handles massive I/O counts and advanced control algorithms without sacrificing deterministic scan times.
Typical use cases include:
- Large-Scale Process Control: Managing continuous manufacturing processes in oil & gas, chemical, and power generation with high-speed logic execution.
- Remote Monitoring & Diagnostics: Utilizing the built-in FTP server and web server to allow engineers to securely access and troubleshoot the controller from anywhere.
- Complex Motion Control: Coordinating multi-axis servo systems and robotics using high-speed floating-point math and dedicated motion instructions.
- Legacy System Upgrades: Replacing older Series 90-70 CPUs in existing infrastructure to gain modern networking capabilities and increased memory capacity.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. We have established a rigorous, multi-stage testing process to ensure every product we ship is 100% functional.
- Visual & Component Inspection: All parts undergo professional cleaning and visual inspection under magnification to ensure no physical damage, corrosion, or compromised components.
- Live System Test: The CPU is installed in a live RX7i test rack with a compatible power supply and run for 24 hours to verify continuous operation, boot sequence, and backplane communication.
- Full-Function Diagnostics: We test both Ethernet ports for link negotiation, verify serial port communication, and execute test logic to confirm memory integrity and boolean execution speed.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
GE-IC698CPE030
Compatibility & Migration Paths
To ensure this IC698CPE030 is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk.
- Firmware/Hardware Revisions: You must confirm your existing RX7i chassis and power supply can support the power draw of the CPE030. Verify your Proficy Machine Edition firmware version supports this CPU model.
- Required Components: This module requires a standard RX7i 9-slot or 12-slot rack. Ensure your power supply (e.g., IC698PSA350) provides sufficient 3.3V and 5V current for the CPU and all installed I/O modules.
- Replacement & Alternatives: The IC698CPE030 is a direct replacement for older RX7i CPUs like the IC698CPE010 or IC698CPE020. If migrating from Series 90-70, note that I/O modules are not cross-compatible.
- Get Expert Help: Unsure about your system’s power budget or firmware requirements? Contact our technical team today for a free compatibility check.
