Description
Key Technical Specifications
- Model Number: CR-GEN0-M6400R3
- Manufacturer: DALSA
- Series: Genie Monochrome Series
- Product Type: Industrial CCD Camera
- Resolution: 640 x 480 (VGA)
- Sensor Size: 1/2-inch or 1/3-inch CCD
- Interface: Gigabit Ethernet (GigE Vision 1.0 compliant)
- Cabling: Standard CAT5e or CAT6 Ethernet
- Exposure Control: Programmable with 1µs granularity
- Trigger Input: Opto-isolated, 2V to 12V typical
DALSA CR-GEN0-M6400R3
Functional Role & Application Analysis
The DALSA CR-GEN0-M6400R3 is a high-performance industrial CCD camera engineered for demanding machine vision applications. It solves the challenge of capturing precise, high-quality images in space-constrained environments by combining a compact form factor with standard GigE connectivity. By utilizing the Genie Framework and Trigger-to-Image-Reliability architecture, this camera ensures dependable image transfer from the sensor to the host PC without dropped frames. Its high dynamic range and low-noise performance make it ideal for extracting critical visual data in varying lighting conditions.
Typical use cases include:
- Automated Quality Inspection: Capturing high-contrast images for surface defect detection, dimensional measurement, and assembly verification on fast-moving production lines.
- Machine Vision Integration: Serving as a reliable vision sensor in robotic guidance systems, barcode reading, and optical character recognition (OCR) applications.
- Legacy System Maintenance: Providing an exact-fit replacement for aging CCD cameras in existing industrial imaging setups to restore inspection accuracy.
- Precision Manufacturing: Monitoring critical processes in semiconductor, electronics, and automotive manufacturing where exact color reproduction and image clarity are mandatory.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable camera is far greater than its purchase price. A faulty vision sensor can cause missed defects and massive scrap rates. We have established a rigorous, multi-stage testing process to ensure every CR-GEN0-M6400R3 we ship is 100% functional and ready for installation.
- Visual & Component Inspection: All cameras undergo professional cleaning and microscopic inspection to ensure the CCD sensor window is pristine, with no physical damage or compromised internal connections.
- Live System Test: The camera is installed in a live test environment and run for continuous operation to verify stable GigE network communication and thermal performance.
- Full-Function Diagnostics: We capture test images to verify the 640×480 resolution, check for dead pixels, and validate exposure and gain controls across the full range.
- Trigger & Sync Verification: Opto-isolated trigger inputs are tested to confirm precise synchronization with external lighting or PLC signals, ensuring accurate image capture timing.
- Warranty Backing: Only cameras that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty.
DALSA CR-GEN0-M6400R3
Compatibility & Migration Paths
To ensure this CR-GEN0-M6400R3 is 100% compatible with your vision system, you must check these key compatibility points. Failure to verify this is a common project risk that leads to costly integration delays.
- Sensor Size Verification: Confirm whether your application requires the 1/2-inch or 1/3-inch sensor variant. Mismatched sensor sizes will alter the field of view and require lens recalibration.
- Software Compatibility: Verify your vision processing software supports GigE Vision 1.0 and GenICam standards. DALSA Sapera LT or compatible third-party libraries are typically required.
- Replacement & Alternatives: This model is directly compatible with standard C-mount lenses. If higher resolution is needed, consider upgrading to the Genie M1024 (1024×768) variant.
- Network Requirements: Ensure your host PC has a dedicated GigE network interface card (NIC) and that Ethernet switches meet GigE Vision bandwidth requirements to prevent packet loss.
- Get Expert Help: Unsure about your system configuration? Contact our technical team today for a free compatibility check and integration verification.
