Description
Key Technical Specifications
- Model Number: VME162PA344SE
- Manufacturer: GE / Motorola | Series: MVME162 VMEbus SBC
- Microprocessor: MC68040 / MC68LC040
- Memory Configuration: 16MB or 32MB Synchronous DRAM (SDRAM)
- Memory Protection: Configurable Parity or ECC-protected DRAM
- Onboard SRAM: 512KB with Battery Backup (CR2032)
- Serial I/O: Two EIA-232-D / EIA-530 / EIA-422 configurable ports
- Expansion Interface: Four IndustryPack (IP) Channels via 3M connectors
- VMEbus Compliance: ANSI/IEEE Std 1014-1987 (VMEbus Specification)
- Operating Temperature: Industrial Grade (-40°C to +85°C Storage)
GE-VME162PA344SE
Functional Role & Application Analysis
The GE VME162PA344SE is a high-performance VMEbus Single Board Computer designed for mission-critical real-time control applications. It is engineered to solve complex processing bottlenecks in legacy industrial systems by providing robust MC680x0-based computing power and high-speed local memory. The integration of IndustryPack interfaces allows for flexible I/O expansion without requiring custom backplane designs.
Typical use cases for this module include:
- Avionics & Defense Systems: Serving as the primary flight control or radar data processing computer in ruggedized VME chassis.
- Industrial Automation: Acting as the central PLC or motion controller in manufacturing lines requiring deterministic VMEbus communication.
- Telecommunications Infrastructure: Managing real-time switching and packet routing in legacy telecom equipment.
- Test & Measurement: Functioning as the data acquisition engine in automated test equipment (ATE) racks.
Our Quality Standard & Testing Process
We understand that the cost of an unreliable part is far greater than its purchase price. A failed SBC in a VME rack can halt an entire production line or test facility. We have established a rigorous, multi-stage testing process to ensure every VME162PA344SE we ship is 100% functional.
- Visual & Component Inspection: Every board undergoes strict visual inspection to ensure no physical damage, capacitor degradation, or compromised VME P1/P2 connectors.
- Live System Test: The module is installed in a live VME test rack and run for 24 hours to verify continuous operation, backplane arbitration, and thermal stability.
- Full-Function Diagnostics: We execute comprehensive POST routines, verify SDRAM integrity, test IndustryPack slot communication, and validate all serial port configurations.
- Warranty Backing: Only parts that pass all diagnostic tests are approved for shipment and backed by our full 12-month warranty, covering hardware and component failures.
GE-VME162PA344SE
Compatibility & Migration Paths
To ensure this VME162PA344SE is 100% compatible with your system, you must check these key compatibility points. Failure to verify this is a common project risk that leads to integration delays.
- VMEbus Backplane: Confirm your chassis supports standard VMEbus (ANSI/IEEE 1014-1987) and provides adequate power to the P1/P2 connectors.
- Memory Configuration: Verify if your application requires Parity or ECC memory protection. The board configuration is determined by switch settings and resistor population options.
- IndustryPack Modules: If using IP expansion, ensure your IndustryPack modules are compatible with the MVME162 IP interface channels and that you have the correct 3M adapter cables.
- Get Expert Help: Unsure about your system’s VMEbus timing or memory configuration? Contact our technical team today for a free compatibility check before placing your order.
